JOYKOO LFP 100Ah

1)JOYKOO 100Ah LiFePO4 cells are mainly used for EV and Solar applications.

2)It can be charged at 1C rate, and discharged at 1C continuously, with more than 100Ah capacity, it is one of the most popular prismatic models.

3)The cells are with blue PVC color, printed with BIS or CE certification, cycle life more than 6000 times.

4)The package is 10pcs for a small carton, inside have sponge sheet to protect it.

5)The cells have got the certification for UL, CE, ROHS, BIS, MSDS, UN38.3.

Service Hotline

86-13428992430 (Mr.Li)

Rated Voltage

3.2V

Nominal Capacity

100Ah

Organization way

LiFePO4 single cell

Standard Charging Current

0.5C(50A)

Standard Discharging Current

0.5C(50A)

End of Charging Voltage

3.65V

End of Discharging Voltage

2.5V

Standard Charging Mode

CC/CV

Max. Continuous Charging Current

1C(100A)

Max. Continuous Discharging Current

1C(100A)

Weight of Single Cell

1.98kg

Inner Resistance(Impedance)

≤0.5mΩ (AC Impedance 1kHz)

Dimensions

Length:116mm,Width:160mm, Thickness:50.0mm

Operating Temperature

Charging:0°C~45°C, Discharging: -20°C~60°C

Storage Temperature

Storage Temperature: -20°C~60°C
