JOYKOO EPS-10000

1)JOYKOO EPS-10000 All in one 10000Wh LiFePO4 battery with Smart BMS and MPPT inverter for household energy storage system use.

2)It can be charged by solar PV panels directly, and can output 110-230V voltage

3)We used High frequency inverter for this product, so it is small and light weight.

4)The portable design is easy for customers to move or take out of the house.

5)The inverter is 5.5KW, but battery module can be paralleled, the single battery module is 5KW,support for max 15pcs in parallel. So total output can reach 75KW.




Service Hotline

86-13428992430 (Mr.Li)

EPS10000-Stackable Emergency Power Supply Parameter
Item Description Parameter
Product Name Household Energy Storage System
Brand Name JOYKOO
Model Number EPS10000
Battery Type Lithium Ion, LiFePO4
Cell Type LFP Prismatic cell-3.2V 102Ah
Rated Capacity 51.2V102Ah
Rated Total Energy 10445Wh
Rated Voltage 48V
Voltage Range 40.50~54.75V
MPPT Voltage Range 120-450Vdc
Solar Charging Current 60A
Rated Output Power 5.5KW
Rated Output Voltage 230Vac±5%
 Output Frequency Range 50Hz ± 0.3Hz /60Hz ±0.3 Hz
Efficiency input>95%,output>85%
 Weight 105kg
 Size (height * width * depth) 580*260*1320mm
 Protection Class IP45
 Cooling Mode Intelligent temperature control fan air cooling
Discharge Waveform Pure sine wave
