JOYKOO ESS-5000M

1)JOYKOO ESS-5000M is a 5000Wh LiFePO4 battery module with Smart BMS for household or public energy storage system use.

2)It can support for max 15pcs in parallel, so total energy can be max 75KW. It is mainly used for Telecom and commercial system like Bank,
date center and electricity power station.

3)Our BMS over current is more than 400Amp, continuously discharge current is 200Amp, it can start all Power frequency inverters
and High frequency inverters both. You don’t need to worry about the over current protection problem when start the whole systems.

4)JOYKOO BMS can communicate with most of the big brand inverters like Growatt/Goodwe/SMA/Victron/Pylontech/deye/SRNE/
Sofarsolar/voltronic/Solis/Soroups etc.





Service Hotline

86-13428992430 (Mr.Li)

ESS5000M  Industry Use Energy Storage System Parameter
Item Description Parameter
Product Name Industry Use  Energy Storage System
Brand Name JOYKOO
Model Number ESS5000M
Battery Type Lithium Ion, LiFePO4
Cell Type LFP Prismatic cell-3.2V 102Ah
Rated Capacity 48V102Ah
Rated Total Energy 4896Wh
Rated Voltage 48V
Voltage Range 40.50~54.75V
MPPT Voltage Range 120-450Vdc
Rated Output Voltage 230Vac±5%
 Output Frequency Range 50Hz ± 0.3Hz /60Hz ±0.3 Hz
Efficiency input>95%,output>85%
 Weight 45kg
 Size (height * width * depth) 440*176*580mm
 Protection Class IP45
