1)JOYKOO ESS-5000S is a 5000Wh LiFePO4 battery module with Smart BMS for household energy storage system use.
2)It can support for max 15pcs in parallel, so total energy can be max 75KW. It is mainly used for Home solar systems.
3)Our BMS over current is more than 400Amp, continuously discharge current is 200Amp, it can start all Power frequency inverters and
High frequency inverters both. You don’t need to worry about the over current protection problem when start the whole systems.
4)JOYKOO BMS can communicate with most of the big brand inverters like Growatt/Goodwe/SMA/Victron/Pylontech/deye/SRNE/
Sofarsolar/voltronic/Solis/Soroups etc.
86-13428992430 (Mr.Li)
| ESS5000S-Stackable Energy Storage System Parameter | |
| Item Description | Parameter |
| Product Name | Household Energy Storage System |
| Brand Name | JOYKOO |
| Model Number | ESS5000S |
| Battery Type | Lithium Ion, LiFePO4 |
| Cell Type | LFP Prismatic cell-3.2V 102Ah |
| Rated Capacity | 48V102Ah |
| Rated Total Energy | 4896Wh |
| Rated Voltage | 48V |
| Voltage Range | 40.50~54.75V |
| MPPT Voltage Range | 120-450Vdc |
| Solar Charging Current | 60A |
| Rated Output Power | 5.5KW |
| Rated Output Voltage | 230Vac±5% |
| Output Frequency Range | 50Hz ± 0.3Hz /60Hz ±0.3 Hz |
| Efficiency | input>95%，output>85% |
| Weight | 45kg |
| Size (height * width * depth) | 605*200*485mm |
| Protection Class | IP45 |
